| Name: | INVINCIBLE |
| Type: | Battlecruiser |
| Keel: | 01/04/1906 |
| Launched: | 13/04/1907 |
| Completed: | 15/03/1909 |
| Builder: | Armstrong, Whitworth & Co |
| Yard: | Elswick |
| Yard Number: | 785 |
| Dimensions: | 17482disp - 20420disp, 530.0 x 78.4 x 26.0(draft)ft |
| Engines: | 4 x Steam turbines, Parsons type, 46500shp |
| Engines by: | Humphrys, Tennant & Co, Deptford |
| Propulsion: | 4 x Screws, 26.6knots |
| Construction: | Steel |
| Armament: | 4 x 2 x 12.0ins and 16 x 1 x 4.0ins QF guns; |
| 5 x 18.0ins torpedoes (1 x aft, 2 x 2 x broadside) | |
| History: | |
| 15/03/1909 | British Royal Navy |
| 31/05/1916 | Sank |
| Comments: | The turbines were actually subcontracted to John Brown & Co Ltd, Glasgow |
| 31/05/1916: Hit by 11.0ins shells from LUTZOW & DERFFINGER at the Battle of Jutland | |
| Shell penetrated the front of Q turret, blew off roof & detonated the midships magazines | |
| She immediately broke in two & sank. 1026 crew died |
Above photo is copyright of Newcastle City Libraries
Above photo is copyright of South Shields Libraries
Above photo is copyright of the Imperial War Museum. CLICK to enlarge/BACK to return
Above photo is courtesy of Photoship
Above photo is copyright of the Imperial War Museum
Above photo is copyright of the Imperial War Museum
Above photo is copyright of the Imperial War Museum
Above: The end at Jutland. Photo is copyright of the Imperial War Museum
Profile & Deck plans courtesy of Dr Dan Saranga. Click HERE to enlarge
